Nowadays, the cameras are widely used to detect the intrusion with AI video analytic. However, the cameras has its limitation in detecting particularly under the challenging conditions for examples,at night, rainy, snowy or foggy days.
By adding a radar module to the security camera,the security level can be greatly enforced. The radar can work well in the rain, snow, fog, and even in the night, and it can detect the target with the high resolution. So, this radar video integrated terminal can work all the day and night, and make alarm to the back-end on any intrusion.
Moreover, with connection to alarm panel, remote notification can be realized; with connection to ONVIF network video recorder, intrusion events can be recorded. You will feel comfortable with this new security technology. This radar video integrated terminal has a detection range up to 60 meters for human and also vehicles. It is a very good choice for your security system upgrade.
| Model | AXPW60-6/4F | AXPW60-6/8F |
| Detection Range | Up to 50m (walkers) | Up to 60m (walkers) |
| Target Classification | Human | |
| Target Velocity | -20 ~ 20m/s | |
| Detection Accuracy | High detection accuracy with low false alert rate (up to 99.99% accurate detection against 1 false alert weekly in lab condition) | |
| Simultaneous Tracking | 8 walkers | |
| NTP | Supported | |
| Self-Diagnose | Supported | |
| Alarm Zones | Up to 4 customized alarm zones with different security levels. | |
| Line-cut Alarm | Supported | |
| Cameras | 1Channel ,HD 1080 2MP 1920×1080 @25fps H.264 Infrared Supplement Light (Day & Night)1/2.9″ 2 Megapixel CMOS, 0.011lux, F1.6 | |
| Radar | FMCW MIMO RADAR 60GHz, FOV120° | |
| Video/image Capture | Full HD 1080p daylight and lowlight | |
| Strobe Siren Alarm | 100 dB | |
| Bracket | Universal Type | |
| Communication Interface | RJ45 | |
| Alarm Output | NO/NC Relay Output(0.5A/125AC) *1 | |
| Protocol | TCP/IP | |
| Installation | Power and Ethernet required. 2.5m above the ground. | |
| Power Supply | DC 12V ＜ 3A/ Power over Ethernet (POE) | |
| Power Consumption | 20 W | |
| IP Rating | IP66 | |
| Working Temprature | -20 ~ 60°C | |
| Dimension | 219*126*89mm | |
| Weight | 0.8kg | |
| Certification | CE, FCC | |
The perimeter security alarm software is to manage multiple perimeter surveillance terminals, AI-video boxes with security radar and video surveillance cameras, integrated smart algorithm. The perimeter security alarm management platform software is the hub of the whole perimeter security system. When the intruder enters the alarm zone area, the radar sensor delivers the intrusion location through active detection, accurately determines the type of intrusion with AI vision, records video of the intrusion process, and reports to the perimeter security alarm management platform, so active, three- dimensional monitoring and early warning of the perimeter is addressed.
Smart radar AI-video perimeter security system can work with the security system in the market including CCTV and Alarm System. The perimeter surveillance terminals and smart AI boxes supports ONVIF & RTSP, also comes with alarm outputs like relay and I/O. Besides, the SDK/API is available for third party security platform integration.
