The perimeter security radar is typically developed for intrusion detection inside or outside the physical fence or wall. By adopting MIMO RF antenna design and FMCW signal processing technology, the radar has the characteristics of high accuracy, resolution and sensitivity. The radar outputs targets with sufficient data as target type, distance, speed, and angle.
Through intelligent AI learning algorithms, radar is able to distinguish human, vehicles, and others, effectively filtering false targets caused by trees and grass. This radar supports customization of included and excluded zones via web interface, and independently works as an intrusion detection sensor to a third party alarm device. It can also output target position to activate the CCTV camera, and be integrated into the security platform.
Compared to other traditional perimeter security technologies, perimeter security radar has much better performance in various adverse weather conditions such as rain, salju, fog, haze, and dust. It can always report any potential intrusion events with minimum false rate.
| Modél | AXPR200-L |
| Jenis Radar | Frékuénsi Modulated Continuous Gelombang (FMCW) |
| Pita frékuénsi | 24GHz |
| Refresh Laju | 10Hz |
| Rentang deteksi (Manusa) | up to 220m (722ft) |
| Rentang deteksi (Kandaraan) | up to 300m (984ft) |
| Laju Target anu tiasa dideteksi | 0.05-30Ibu (0.16-98.4ft/s) |
| Médan Éféktif Témbongkeun (Horizontal) | ± 10° |
| Widang sawangan anu épéktip (Nangtung) | ±6.5° |
| Nyukcruk Simutaneous | 32 |
| Akurasi Jarak | ± 1m (± 3,3 ft) |
| Akurasi sudut | ± 1° |
| Resolusi rentang | 1.5m (4.9ft) |
| Kaluaran Alarm | NO / NC Relay *1;GPIO *1 |
| Sistem operasi | Diwangun-di Linux |
| Antarbeungeut Komunikasi | Ethernet & RS485 |
| Sasayogian tanaga | DC 12V 2A / POE |
| Konsumsi Daya | 9W |
| Suhu Operasi | -40 ~ 70 ℃ (-40 ~ 158℉) |
| Diménsi | 300*130*50mm (11.8*5.1*2di) |
| Beurat | 1.64kg (3.6pon) |
| Jangkungna instalasi | 1.5 ~ 4m (4.9 ~ 13,1 ft) |
| Sertifikasi | CE, FCC |
Parangkat lunak alarem kaamanan perimeter nyaéta pikeun ngatur sababaraha terminal panjagaan perimeter, Kotak AI-video sareng radar kaamanan sareng kaméra panjagaan pidéo, algoritma pinter terpadu. Parangkat lunak platform manajemén alarem kaamanan perimeter mangrupikeun hub sadaya sistem kaamanan perimeter. Sabot intruder asup ka wewengkon zona alarm, sensor radar delivers lokasi intrusion ngaliwatan deteksi aktip, akurat nangtukeun jenis intrusion kalawan visi AI, ngarekam video tina prosés intrusion, sareng ngalaporkeun ka platform manajemén alarem kaamanan perimeter, jadi aktip, tilu- monitoring diménsi sarta warning awal perimeter nu kajawab.
Sistem kaamanan perimeter AI-video pinter radar tiasa dianggo sareng sistem kaamanan di pasar kalebet CCTV sareng Sistem Alarm. Terminal panjagaan perimeter sareng kotak AI pinter ngadukung ONVIF & RTSP, ogé hadir sareng kaluaran alarem sapertos relay sareng I / O. Salian ti éta, SDK / API geus sadia pikeun integrasi platform kaamanan pihak katilu.
